LR7-60HVDA
530~555M
LR7-60HVDA
530~555MClass A Fire Certification
Industry's first mass-produced module with Class A fire safety certification
Anti-Ignition
Source-level prevention of hot spots and arcing
Fire-Resistance
Effectively contains fire spread, securing critical rescue time
Higher Power Generation
A+ anti-shading, 70% power loss cut
15
Y
Product
Warranty
Warranty
30
Y
Performance
Warranty
Warranty
Bifacial Power
Generation
Generation
Hi-MO X10
Fire-Resistant
LR7-60HVDA
Mechanical Parameters
Cell Orientation
120 (6×20)
Junction Box
IP68, three diodes
Output Cable
4mm2, +400, -200mm/±1400mm
length can be customized
Glass
Dual glass 2.0mm+2.0mm, Special Fire-Resistant Glass
Frame
Anodized aluminum alloy frame
Weight
28
kg
Dimension
1990×1134×30mm
Packaging
36pcs per pallet / 180pcs per 20'GP / 792pcs per 40'HC
Electrical characteristics with different rear side power gain
Pmax /W
535
562
589
615
642
669
Voc/V
45.05
45.05
45.05
45.15
45.15
45.15
Isc /A
15.00
15.75
16.50
17.25
18.00
18.75
Vmp/V
37.27
37.27
37.27
37.37
37.37
37.37
Imp /A
14.36
15.07
15.79
16.47
17.18
17.90
Pmax gain
0%
5%
10%
15%
20%
25%
Tolerance:
Length: ±2mm
Width: ±2mm
Electrical Characteristics
STC : AM1.5 1000W/m2 25℃
NOCT : AM1.5 800W/m2 20℃ 1m/s
Test uncertainty for Pmax ±3%
Module Type
Testing Condition
Maximum Power (Pmax/W)
Open Circuit Voltage (Voc/V)
Short Circuit Current (Isc/A)
Voltage at Maximum Power (Vmp/V)
Current at Maximum Power (Imp/A)
Module Efficiency(%)
LR7-60HVDA-530M
STC
530
44.95
14.90
37.17
14.26
23.49
LR7-60HVDA-535M
STC
535
45.05
15.00
37.27
14.36
23.71
LR7-60HVDA-540M
STC
540
45.15
15.10
37.37
14.45
23.93
LR7-60HVDA-545M
STC
545
45.25
15.20
37.47
14.55
24.15
LR7-60HVDA-550M
STC
550
45.35
15.30
37.57
14.64
24.37
LR7-60HVDA-555M
STC
555
45.45
15.40
37.67
14.73
24.59
Operating Parameters
Operational Temperature
-40℃ ~ +85℃
Power Output Tolerance
0 ~ 3%
Maximum System Voltage
DC1500V (IEC)
Maximum Series Fuse Rating
30A
Nominal Operating Cell Temperature
45±2℃
Protection Class
Class II
Fire Rating
IEC Class C
Mechanical Loading
Front Side Maximum Static Loading
5400Pa
Rear Side Maximum Static Loading
2400Pa
Hailstone Test
25mm Hailstone at the speed of 23m/s
Temperature Ratings (STC)
Temperature Coefficient of Isc
+0.050%/℃
Temperature Coefficient of Voc
-0.200%/°C
Temperature Coefficient of Pmax
-0.260%/°C
Specifications included in this datasheet are subject to change without notice. LONGi reserves the right of final interpretation.
